LT-568 Tire Changer
- SKU
- CW-C0001
- Unit
- each
- Min. Order
- 1
Contact for Pricing
Volume pricing quoted per order.
LT-568 Tire Changer — tire service tool: Particularly suitable for truck, farm vehicle, passenger car, and industrial vehicle tires with deep-grooved rims and tubeless tires with ring.
Features
- •Particularly suitable for truck, farm vehicle, passenger car, and industrial vehicle tires with deep-grooved rims and tubeless tires with ring
- •All movements of working parts guided by the mobile arm
- •Low-voltage control handle
- •Clockwise and anticlockwise rotation of chuck
- •Universal self-centering chuck
- •Hydraulic motor with quick rotation
Description
LT-568 Tire Changer is a tire service tool. Particularly suitable for truck, farm vehicle, passenger car, and industrial vehicle tires with deep-grooved rims and tubeless tires with ring. All movements of working parts guided by the mobile arm. Low-voltage control handle.
Specifications
| Noise | less than 70db |
|---|---|
| Packing Size | 2200x1600x900mm |
| Power Supply | 110V/220V/380V 50/60HZ |
| Rim Diameter | 14"-26" |
| Gearbox Motor | 1.8kw 380V-3Ph (220V optional) |
| Max Wheel Width | 780mm |
| Bead Break Force | 2500Kgf |
| Max Wheel Weight | 500kg |
| Net/Cross Weight | 320/350kgs |
| Max Wheel Diameter | 1600mm |
| Hydraulic Pump Motor | 1.5kw 380V-3Ph (220V optional) |
| Operation Control Voltage | 24V |
