L0402 PRO 3D Wheel Alignment System
- SKU
- CW-L0402
- Unit
- each
- Min. Order
- 1
Contact for Pricing
Volume pricing quoted per order.
L0402 PRO 3D Wheel Alignment System — tire service tool: Beam Automatic Tracking System.
Features
- •Beam Automatic Tracking System
- •5 Million Pixel Industrial Camera
- •50,000+ Vehicle Model Database
- •8-12cm Rolling Compensation
- •Ultra-fast Data Acquisition via 5G cameras for axle data
- •High Mobility: movable tower, no need to bolt unit to floor, recalibration-free relocation
- •User-friendly handheld reflectors, easy to position precisely
- •Intuitive operation with step-by-step navigation and voice-guided procedures
- •Direct Documentation via integrated printer
- •Uses new USB3.0 interface (5.0Gbps transmission, 10x faster than USB2.0)
- •5-million-pixel measurement camera, 20fps frame rate (5x faster than 4fps USB2.0 cameras)
- •3D four-wheel positioning; only needs a short push distance (half of the traditional 50cm) to measure tire data
Description
L0402 PRO 3D Wheel Alignment System is a tire service tool. Beam Automatic Tracking System. 5 Million Pixel Industrial Camera. 50,000+ Vehicle Model Database.
Specifications
| Camber | ±2° / ±20° |
|---|---|
| Camera | 5mp |
| Caster | ±4° / ±20° |
| Toe-in | ±2° / ±20° |
| Weight | 204kg |
| Printer | HP |
| Wheelbase | ±2mm / 4000mm |
| Performance | 0.5kw |
| Wheel Track | ±2mm / 2500mm |
| Thrust Angle | ±2° / ±10° |
| Tire Diameter | ±2mm / 1000mm |
| Display Accuracy | 1'/0.01°/0.1mm |
| Operating System | Windows |
| Operating Voltage | AC 220V (10A) |
| Integrated Display | 27 inch |
| Operating Frequency | 50-60Hz |
| King Pin Inclination Angle | ±6° / ±20° |
