ET500 New energy vehicle battery pack air tightness tester (high voltage)
- SKU
- CW-S010011
- Unit
- each
- Min. Order
- 1
Contact for Pricing
Volume pricing quoted per order.
ET500 New energy vehicle battery pack air tightness tester (high voltage) — diagnostic tool: Battery pack and liquid cooling system share high and low pressure.
Features
- •Battery pack and liquid cooling system share high and low pressure
- •High-sensitivity pressure sensing with high test accuracy and stability
- •Automatically detects pressure inside the battery pack, auto-advances to next stage once pressure is reached, with more accurate segmented inflation
- •Pressure dial displays process pressure curve in real time
- •High-pressure automatic protection with alarm prompts when test fails or is abnormal
Description
ET500 New energy vehicle battery pack air tightness tester (high voltage) is a diagnostic tool. Battery pack and liquid cooling system share high and low pressure. High-sensitivity pressure sensing with high test accuracy and stability. Automatically detects pressure inside the battery pack, auto-advances to next stage once pressure is reached, with more accurate segmented inflation.
Specifications
| Interface | RS232/USB |
|---|---|
| Power Input | AC90~264V/40~60Hz |
| Test accuracy | ±5pa |
| Air Requirements | 0.4~1.0MPa Dry Compressed Air |
| Working Humidity | 10%~90% |
| Sensor Resolution | 1pa |
| Test Pressure Range | 0~500Kpa |
| Working Temperature | -10~55°C |
| Air Intake/Test Interface | Φ8mm Ttrachea / Φ6mm Trachea |
