EB240 New energy vehicle battery pack cell balancer
- SKU
- CW-S010008
- Unit
- each
- Min. Order
- 1
Contact for Pricing
Volume pricing quoted per order.
EB240 New energy vehicle battery pack cell balancer — piece of shop equipment: 24 balancing channels & single-cell balancing design: independent single-cell balancing solution, supports single-cell.
Features
- •24 balancing channels & single-cell balancing design: independent single-cell balancing solution, supports single-cell precise balancing; supports up to 2 groups of module balancing, up to 12 strings of cells per group
- •Intelligent cell balancing: supports ternary lithium, lithium iron phosphate, lithium manganese oxide, and lithium titanate; supports balancing maintenance parameter settings; presets voltage range per battery type; auto-switches charging/discharging modes
- •High precision & balancing gain: high-precision acquisition of single-cell voltage parameters
- •Safety assurance: overvoltage, undervoltage, overcurrent protection, output short circuit, reverse connection, and overtemperature protection
- •Log management & data visualization: differentiated comparison between before/after balancing; exports balancing data; real-time monitoring of each cell voltage and balancing status
Description
EB240 New energy vehicle battery pack cell balancer is a piece of shop equipment. 24 balancing channels & single-cell balancing design: independent single-cell balancing solution, supports single-cell precise balancing; supports up to 2 groups of module balancing, up to 12 strings of cells per group. Intelligent cell balancing: supports ternary lithium, lithium iron phosphate, lithium manganese oxide, and lithium titanate; supports balancing maintenance parameter settings; presets voltage range per battery type; auto-switches charging/discharging modes. High precision & balancing gain: high-precision acquisition of single-cell voltage parameters.
Specifications
| Power | 600W Max |
|---|---|
| Display | 7-inch TFT LCD screen, resolution 1024×600 |
| Power input | AC90~264V/40~60Hz |
| Charge control | Constant current charging + constant voltage charging |
| Discharge mode | Constant current discharging + constant voltage discharging |
| Battery interface | 24Pin |
| Equalize interface | 16Pin |
| Protection function | Input over-current protection, over-voltage protection, output over-current protection, over-temperature protection |
| Wireless communication | WiFi and BT (external WiFi antenna) |
| Communication Interface | SMA, USB-Device |
| Current detection accuracy | ±1%FS±0.05A (maximum range 5A) |
| Voltage detection accuracy | ±0.1%FS±2mV (maximum range 5V) |
| Equalize number of channels | 2×12Pin |
| Charge and discharge current range | 0.1~5A Max |
| Charge and discharge voltage range | 1.8~4.2V |
| Battery temperature detection accuracy | ±2°C (-25°C~85°C) |
