TLT240SCA
- SKU
- CW-L0508
- Unit
- each
- Min. Order
- 1
Contact for Pricing
Volume pricing quoted per order.
TLT240SCA — vehicle lift: 24V low voltage control box (IP54 level) for operator safety.
Features
- •24V low voltage control box (IP54 level) for operator safety
- •Cylinder travel limit switch protects cylinder and extends lifespan
- •Emergency lowering valve can be manually operated to lower lift safely if power is off
- •Anti-explosion valve slows/stops lowering in case of oil explosion, protecting operator and vehicle
- •CE-STOP function with safety alarm beep warns operators to keep a safe distance when lift lowers to about 250mm from ground
- •Door rubber pad protects car door from damage in collision
- •More lifting pads with different heights meet requirements for light lorries and SUVs
- •Fully automatic unlocking safety device, operated only with UP/DOWN button
- •Cable and oil pipe fully concealed for a decent, elegant appearance
- •Double hydraulic cylinder and high-strength chain drive for stable, smooth lifting and lowering
- •Wire rope equalization system forces synchronous movement of two carriages, preventing vehicle tilting
Description
TLT240SCA is a vehicle lift. 24V low voltage control box (IP54 level) for operator safety. Cylinder travel limit switch protects cylinder and extends lifespan. Emergency lowering valve can be manually operated to lower lift safely if power is off.
Specifications
| Colors | red, grey, Volkswagen blue, Hyundai blue, GM blue (Buick blue) |
|---|---|
| Warranty | 1 year |
| Swing Arm | 2-stage (800-1200)*4 |
| Power Unit | Domestic (Overhead), 2.2KW 10L |
| Control Box | Full electronic control system |
| Lifting Pad | Double screws lifting pad |
| Product Grade | Economical |
| Safety Device | CE-STOP, cylinder travel limit module, anti-explosion valve, emergency lowering valve |
| Unlocking System | Full automatic |
| Relative Humidity | Temperature +30°C, relative humidity 80% |
| Working Temperature | -5°C ~ +40°C |
| Height Above Sea Level | No more than 2000m |
| Transport/Storage Temperature | -5°C ~ +40°C |
