Telehandler — YW735
- SKU
- HE-YW735
- Unit
- each
- Min. Order
- 1
Contact for Pricing
Volume pricing quoted per order.
Features
- •Multifunctional joystick for simultaneous lift, telescope and leveling operations
- •Dual-stage air filtration with side-by-side oil cooler and fan for heat dissipation
- •Quick-change attachment capability reduces equipment costs
- •All-glass cab with wide field of view
- •Heavy-duty axle with high load capacity and transmission efficiency
Description
A multifunctional joystick enhances operational precision and productivity, capable of simultaneously and smoothly performing lifting, telescoping and leveling operations for true multitasking. A dual-stage air filtration system reduces dust entering the filter element, with the oil cooler and fan installed side-by-side for better heat dissipation. Quick-change capability lets a single machine perform multiple tasks, reducing equipment procurement and operating costs. An all-glass cab delivers a wide field of view for enhanced work efficiency. The heavy-duty axle provides high load-bearing capacity and superior transmission efficiency.
Specifications
| Axle | Heavy-Duty Axle |
|---|---|
| Type | 16/70R24 |
| Power(kw) | 77.3 |
| Engine Type | YCD4M22T-105 turbocharged diesel |
| Outline(mm) | 5300*2300*2510 |
| Intake Method | Turbocharging |
| Working Valve | Proportional working valve |
| Wheel Base(mm) | 3405 |
| Wheel Tread(mm) | 1855 |
| Max.Capacity(kg) | 3500 |
| Max.Outreach(mm) | 2700 |
| Engine Speed(r/min) | 2400 |
| Operating Weight(kg) | 7500 |
| Max.Lifting Height(mm) | 7000 |
| Max.Travel Speed(km/h) | 35 |
| Min.Turning Radius(mm) | 4685 |
| Min. Ground Clearance(mm) | 400 |
| Lifting Capacity At Max Outreach(kg) | 1700 |
